pneumatic 4 way ball valve
-size：dn15~dn150
-connection standard：pn10/16, ansi150, din16, jis10k, 16k
-working temperature：-15~300℃
-working pressure：pn10~pn64
-body：wcb、ss304、ss316、ss304l、ss316l
-ball：wcb、ss304、ss316、ss304l、ss316l
-seat：ptfe、hard metal seal
-medium：steam, air, gas, ammonia, oil, water, etc
-operating：pneumatic
ordering hotline：021-54150349
- product introduction
- product parameters
only needs to operate wrench or actuator to rotate the ball 90 degrees for 4 way ball valve. it can switch the flow direction of the two kinds of media at the same time. it is convenient and fast to realize the multi-purpose effect of one valve. the valve core and light neck are made of austenitic stainless steel, and the seat material is ptfe, which can achieve good corrosion resistance and prolong the service life of the valve.
2. seat
3. body
4. ball
5. trunion mounted valve seat
6. wear-resistant sleeve
9. stem
10. thrust washer
11. o-ring
12. packing
13. packing ring
3. body
4. ball
5. trunion mounted valve seat
6. wear-resistant sleeve
9. stem
10. thrust washer
11. o-ring
12. packing
13. packing ring
