manual flange ball valve
-size：dn15~dn200
-connection standard：pn10/16, ansi150, din16, jis10k, 16k
-working temperature：-15~300℃
-working pressure：pn10~pn100
-body：wcb、ss304、ss316、ss316l、2205、2207
-disc：wcb、ss304、ss316、ss316l、2205、2207
-seat：ptfe、ppl、hard metal seal
-medium：gas, oil, water, powder particles
-operating：manual
ordering hotline：021-54150349
- product introduction
- product parameters
the body of the flange ball valve is ludox, high platform valve body, no need to do bracket, will not cause the torque error of the valve, so that the valve can not open or fully close. the ball is solid and with high processing precision, won’t cause the excess material remain and pollution.
5. ball
6. seat
7. body
8. anti-static device
9. stem
10. thrust washer
11. o-ring
12. packing
13. packing ring
6. seat
7. body
8. anti-static device
9. stem
10. thrust washer
11. o-ring
12. packing
13. packing ring
